Python

Python & openpyxl – If the fraud team tells you to do something; do it quickly!

A member of our Fraud team contacted me unexpectedly at work.

Hey. I got this excel workbook of a customer’s statement with the data spread across multiple sheets. Do you know how to consolidate them into one sheet?

“OK,” I thought, “It can’t be that hard.”

She sent me the workbook. It had 447 sheets in it! The statement was initially in a PDF format and the Fraud team exported it to Excel. This resulted in a sheet for each page; looking like this:

The data that we were interested in was between A7 and E29 on each page. I visually spot checked half a dozen sheets across the workbook and they were in similar format

Ditching VBA for openpyxl

In yesteryear; I would have VBA inside Excel to consolidate the sheets. But I felt it was time to grow up from VBA and see what python had to offer.

After a quick Google; I came across Data Camp’s Python Excel Tutorial.

It was surprisingly quick and easy to program up. I honestly thought it would have taken me as long; if not longer in VBA.

Here is the scratch code for your perusal

import openpyxl
import logging
from datetime import datetime
import csv

# Formats a row into a format for the delimited file
def format_row(in_record):

    try:
        in_record[0] = datetime.strftime(in_record[0], "%Y-%m-%d")  # Converts the python date to YYYY-MM-DD
    except TypeError as e:
        root_logger.warning("Cannot convert " + in_record[0] + " to date/time")

    in_record[1] = in_record[1].replace("\n", " \u21B5")    # Adds in a return arrow

    if in_record[2] == None:
        in_record[2] = ""

    if in_record[3] == None:
        in_record[3] = ""

    return in_record


if __name__ == '__main__':

    now = datetime.now()

    log_formatter = logging.Formatter("%(asctime)s [%(threadName)-12.12s] [%(levelname)-8.8s]  %(message)s")
    root_logger = logging.getLogger()
    root_logger.setLevel(logging.INFO)

    log_console_handler = logging.StreamHandler()
    log_console_handler.setFormatter(log_formatter)
    root_logger.addHandler(log_console_handler)

    final_array = []

    wb = openpyxl.load_workbook("CONSOLIDATEDExcel.xlsx")

    for focus_sheet_name in wb.sheetnames:

        root_logger.info("Processing sheet: " + focus_sheet_name)

        focus_sheet = wb[focus_sheet_name]
        root_logger.debug("Total number of rows: " + str(focus_sheet.max_row) + '. And total number of columns: ' + str(focus_sheet.max_column))


        if focus_sheet["A6"].value == "Date":   # Checks for the key field "Date" in position A6

            my_list = []

            for sheet_row in focus_sheet.iter_rows(
                min_row=7, max_row=26, min_col=1, max_col=5,    # Gets specific section of the worksheet
                values_only=True):

                sheet_row_list = list(sheet_row)

                if sheet_row_list[0] != None:   # Ignore lines that are blank
                    final_array.append(format_row(sheet_row_list))
        else:
            root_logger.info("Cannot find key column \"DATE\".  Skipping sheet")


    # Output records to a tab delimited file
    with open("Consolidated_output.tab", 'w', newline='', encoding="utf-8") as myfile:
        wr = csv.writer(myfile, quoting=csv.QUOTE_ALL, delimiter="\t")
        wr.writerows(final_array)

Also; it ran blindingly quick – as quick as I feel in VBA with Application.ScreenUpdating = False

Anyway; Fraud team was happy I turned their request around quickly. I’m guessing if the fraud team is involved – someone is about to have a bad day.

October 25, 2024 by Python VBA / VBS 0

Python – Unpacking a COMP-3 number

New business requirement today.  We have some old mainframe files we have to run through Qlik Replicate.

Three problems we have to overcome:

  1. The files are in fixed width format
  2. The files are in EBCDIC format; specifically Code 1047
  3. Inside the records there are comp-3 packed fields

The mainframe team did kindly provide us with a schema file that showed us the how many bytes make up each field so we could divide up the fixed width file by reading in a certain number of bytes per a field.

Python provided a decode function to decode the fields read to a readable format:

focus_data_ascii = focus_data.decode("cp1047").rstrip()

The hard part now was the comp-3 packed fields. They are made up with some bit magic and working with bits and shifts is not my strongest suite

I have been a bit spoilt so far working with python and most problems can be solved by “find the module to do the magic for you.”

But after ages of scouring for a module to handle the conversion for me; I had a lot of false leads – testing questionable code with no luck.

Eventually I stumbles upon:

zorchenhimer/cobol-packed-numbers.py

Thank goodness.

It still works with bits ‘n’ shift magic – but it works on the data that I have and now have readable text

I extended the code to fulfil the business requirements:

# Source https://gist.github.com/zorchenhimer/fd4d4208312d4175d106
def unpack_number(field, no_decimals):
    """ Unpack a COMP-3 number. """
    a = array('B', field)
    value = float(0)

    # For all but last digit (half byte)
    for focus_half_byte in a[:-1]:
        value = (value * 100) + ( ( (focus_half_byte & 0xf0) >> 4) * 10) + (focus_half_byte & 0xf)

    # Last digit
    focus_half_byte = a[-1]
    value = (value * 10) + ((focus_half_byte & 0xf0) >> 4)

    # Negative/Positve check.  If 0xd; it is a negative value
    if (focus_half_byte & 0xf) == 0xd:
        value = value * -1

    # If no_decimals = 0; it is just an int
    if no_decimals == 0:
        return_int = int(value)
        return (return_int)
    else:
        return_float = value / pow(10, no_decimals)
        return (return_float)
August 19, 2022 by Code Python 0
